SPLIT BOLT CONNECTORS
Product Details:
Product Description
SPLIT BOLT CONNECTORS
Material Used: BS 2874/Freely cut high quality brass rods
Sizes of Availability:10 mm2 to 500 mm2 Higher or lower sizes are possible with customer demand
Finishing of the Product:Split bolt Connectors are rolled out in natural brass. They are also copper coated/electro tin finished/nickel plated. High conductivity copper also used on demand of the customers.
| SIZE mm2 | ITEM CODE | A (BOLT) A/F | B | C | D (NUT) A/F |
| 6 | MSBC 6 | 10.00 | 24.00 | 3.20 | 12.70 |
| 10 | MSBC 10 | 12.70 | 27.30 | 5.50 | 19.00 |
| 16 | MSBC 16 | 12.70 | 27.30 | 5.50 | 19.00 |
| 25 | MSBC 25 | 14.20 | 28.90 | 6.90 | 19.00 |
| 32 | MSBC 32 | 18.00 | 31.00 | 8.10 | 23.00 |
| 35 | MSBC 35 | 18.00 | 34.80 | 8.10 | 24.00 |
| 50 | MSBC 50 | 23.00 | 42.00 | 9.60 | 27.30 |
| 70 | MSBC 70 | 23.00 | 47.50 | 11.17 | 30.00 |
| 95 | MSBC 95 | 25.40 | 53.00 | 14.00 | 34.30 |
| 100 | MSBC 100 | 30.00 | 60.00 | 14.00 | 37.00 |
| 120 | MSBC 120 | 30.00 | 59.00 | 16.00 | 35.55 |
| 150 | MSBC 150 | 30.00 | 59.00 | 16.00 | 35.55 |
| 185 | MSBC 185 | 32.00 | 59.00 | 18.00 | 38.10 |
| 240 | MSBC 240 | 38.00 | 76.20 | 22.00 | 48.25 |
| 300 | MSBC 300 | 38.00 | 76.20 | 23.00 | 52.45 |
